Main features

1.Used for cutting aluminum and plastic profile at 90^o,45^o

2.Imported carbide saw blade give accuracy processing and high endurance

3.Saw blade rotate smoothly due to high accuracy main spindle

4.Uniform speed and smooth feeding due to gas-liquid damping cylinder

5.One time processing can cut off required length

6.Protective cover is optional

Main Technical Parameter

Cutting Motor Power                      2*2.2kw

Input voltage                            380V  50hz

Main Rotary Speed                       2850r/min

Cutter Diameter                         Inner 30mm   Outside 450mm

Cutting Length                          Min 550mm   Max3700mm

Cutting Width                          90°120*200mm   45°120*165mm

Contour dimension                       4500*1170*1400mm

Weight                                 1500kgs
